CURT 13028 Class 3 Trailer Hitch; 2-Inch Receiver; Drilling Required; Fits Select Ford; Chevrolet; GMC C/K Pickup Trucks
Whatever your task at hand -- whether its launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Chevy Silverado 3500, C30, C3500, C3500HD, Ford F Super Duty, F350, F350 Super Duty, F450 Super Duty, F550 Super Duty, GMC C3500, C3500HD and K3500 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 6,000 lbs. GTW and 600 lbs. TW. It is also compatible with a weight distribution hitch for level towing and a rating of 10,000 lbs. WD and 1,000 lbs. WDTW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2 in. receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
Whatever your task at hand -- whether its launching that boat before daybreak, setting up your camper before the rush or getting a final load to the dump before close -- CURT class 3 trailer hitches offer the strength needed for serious towing. They make it easy to hitch up and Bring It, offering a vehicle-specific fit and the weight capacity to handle a variety of trailers. Custom class 3 hitches are the most common type of receiver hitch for pickup trucks and SUVs. Because of their weight range, they are also found on full-size cars, crossovers and minivans. Each custom-fit class 3 hitch package is made for vehicle-specific mounting. This particular kit fits certain years of the Chevy Silverado 3500, C30, C3500, C3500HD, Ford F Super Duty, F350, F350 Super Duty, F450 Super Duty, F550 Super Duty, GMC C3500, C3500HD and K3500 (see application info to verify vehicle compatibility). It provides a weight carrying capacity of 6,000 lbs. GTW and 600 lbs. TW. It is also compatible with a weight distribution hitch for level towing and a rating of 10,000 lbs. WD and 1,000 lbs. WDTW. CURT class 3 trailer hitches are typically used to attach and haul utility trailers, boat trailers, campers, snowmobile or ATV haulers and more (NOTE: Never exceed the lowest-rated towing component). Each class 3 hitch has a 2 in. receiver tube and is tested in accordance with SAE J684 for safety. To ensure that CURT class 3 receiver hitches have what it takes for serious trailering, they are designed using a hands-on approach and are constructed with rugged, high-strength steel and precise welding. We also protect our class 3 hitches in a co-cured finish of liquid A-coat and black powder coat for superior resistance to rust, chipping and UV damage.
- Made w/A Vehicle-Specific Design For A Custom Fit
- Tested For Safety In Accordance w/SAE J684
- Precisely Welded For Superior Strength And Fit
- Protected By A Durable High-Gloss Black Powder Coat Finish
- Co-Cured In A Rust-Resistant Liquid Bonderite Coating
- Strengthened w/A Cast Welded Seamless Collar
- Equipped w/An Open-Back Receiver For Easy Cleaning
- Backed By A Limited Lifetime Warranty
- Made in USA [may include imported hardware]
Information:
Class 3 Hitch, 2 Receiver, Select Ford, Chevrolet, GMC C/K (Drilling Required); Rated to 6,000 lbs. gross trailer weight and 600 lbs. tongue weight; Compatible with weight distribution hitch (10,000 lbs. WD / 1,000 lbs. WDTW); Engineered with a vehicle-specific design for a custom fit; Concealed main body for OE look and seamless integration with the vehicle; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Protected by a durable high-gloss black powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Equipped with an open-back receiver for easy cleaning; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware)Application Summary:
| Year | Make/Model |
|---|---|
| 1975-1984 | Chevrolet C10 |
| 1986 | Chevrolet C10 |
| 1969-1974 | Chevrolet C10 Pickup |
| 1988-1999 | Chevrolet C1500 |
| 1975-1984 | Chevrolet C20 |
| 1986 | Chevrolet C20 |
| 1970-1974 | Chevrolet C20 Pickup |
| 1988-2000 | Chevrolet C2500 |
| 1975-1984 | Chevrolet C30 |
| 1986 | Chevrolet C30 |
| 1970-1974 | Chevrolet C30 Pickup |
| 1988-2000 | Chevrolet C3500 |
| 1998-2002 | Chevrolet C3500HD |
| 1975-1984 | Chevrolet K10 |
| 1986 | Chevrolet K10 |
| 1969-1974 | Chevrolet K10 Pickup |
| 1988-1999 | Chevrolet K1500 |
| 1975-1984 | Chevrolet K20 |
| 1986 | Chevrolet K20 |
| 1970-1974 | Chevrolet K20 Pickup |
| 1988-2000 | Chevrolet K2500 |
| 1977-1984 | Chevrolet K30 |
| 1986 | Chevrolet K30 |
| 1970-1974 | Chevrolet K30 Pickup |
| 1988-2000 | Chevrolet K3500 |
| 1987 | Chevrolet R10 |
| 1987-1988 | Chevrolet R20 |
| 1989 | Chevrolet R2500 |
| 1987-1988 | Chevrolet R30 |
| 1989-1991 | Chevrolet R3500 |
| 2003-2006 | Chevrolet Silverado 3500 |
| 1987 | Chevrolet V10 |
| 1987 | Chevrolet V20 |
| 1987-1988 | Chevrolet V30 |
| 1989-1991 | Chevrolet V3500 |
| 1963-1996 | Ford F-250 |
| 1963-1996 | Ford F-350 |
| 1999 | Ford F-450 Super Duty |
| 1999 | Ford F-550 Super Duty |
| 1975-1978 | GMC C15 |
| 1970-1974 | GMC C15/C1500 Pickup |
| 1979-1986 | GMC C1500 |
| 1988-1999 | GMC C1500 |
| 1975-1978 | GMC C25 |
| 1969-1974 | GMC C25/C2500 Pickup |
| 1979-1986 | GMC C2500 |
| 1988-2000 | GMC C2500 |
| 1975-1978 | GMC C35 |
| 1969-1974 | GMC C35/C3500 Pickup |
| 1979-1986 | GMC C3500 |
| 1988-2000 | GMC C3500 |
| 1998-2002 | GMC C3500HD |
| 1975-1978 | GMC K15 |
| 1970-1974 | GMC K15/K1500 Pickup |
| 1979-1986 | GMC K1500 |
| 1988-1999 | GMC K1500 |
| 1975-1978 | GMC K25 |
| 1970-1974 | GMC K25/K2500 Pickup |
| 1979-1986 | GMC K2500 |
| 1988-2000 | GMC K2500 |
| 1977-1978 | GMC K35 |
| 1970-1974 | GMC K35/K3500 Pickup |
| 1979-1986 | GMC K3500 |
| 1988-2000 | GMC K3500 |
| 1987 | GMC R1500 |
| 1987-1989 | GMC R2500 |
| 1987-1991 | GMC R3500 |
| 2003-2006 | GMC Sierra 3500 |
| 1987 | GMC V1500 |
| 1987 | GMC V2500 |
| 1987-1991 | GMC V3500 |
| Attributes | |
| ASIN | B00075XCLM |
| Body Shape | Square |
| Box Height in Inches - XA | 19 |
| Box Length in Inches - XA | 41 |
| Box Width in Inches - XA | 9 |
| California Proposition 65 | Yes |
| Class ID | 3 |
| Container Volume Cubic Feet - XA | 0.00000 |
| Container Volume Cubic Meter - XA | 0.00000 |
| Country of Origin (Primary) | US |
| Drilling Required | Yes |
| Emission Code | Legal US |
| Finish | Gloss Black Powder Coat |
| Finish - XA | GLOSS BLACK POWDER COAT |
| GTIN | 00612314528004 |
| Gross Trailer Weight | 6000 lbs. |
| Gross Trailer Weight (lbs.) | 6000 |
| Harmonized Tariff Code (Schedule B) | 8708998180 |
| Hazardous Material Code | N |
| Install Time | 60 Minutes |
| Item Class - XA | MFH |
| Item Height - XA | 7.770 |
| Item Length - XA | 33.750 |
| Item Width - XA | 18.130 |
| Life Cycle Status Code | Available to Order |
| Long Description | Class III Trailer Hitch |
| Main Body Shape | Square |
| Master Case Height Inches - XA | 0.000 |
| Master Case Length Inches - XA | 0.000 |
| Master Case Volume Cubic Feet - XA | 0.00000 |
| Master Case Weight Lbs - XA | 0.000 |
| Master Case Width Inches - XA | 0.000 |
| Material - XA | Carbon Steel |
| Mount Type Description - XA | Blank |
| NAFTA Preference Criterion Code | B |
| Pallet Total Height Inches - XA | 0.000 |
| Pallet Total Weight Per - XA | 0.000 |
| Parcel Allowed - XA | Yes |
| Position | Rear |
| Price Code - XA | 45 |
| Product Weight - XA | 36.000 |
| Rate Class - XA | 70.0, 175.0 |
| Receiver Tube Size | 2.000 in., 2 IN |
| Retail Height - XA | 10.000 |
| Retail Length - XA | 42.000 |
| Retail Width - XA | 21.000 |
| SDR Required Flag | N |
| Sales Family Code - XA | HITCH |
| Sales Family Description - XA | HITCH |
| Sales Group Description - XA | CL 3 |
| Shipping Weight - XA | 42.000 |
| Side Application Type Description - XA | Blank |
| Tariff 301 - XA | No |
| Tongue Weight (TW) | 600 LB |
| Tongue Weight(TW) | 600 LB |
| Truckload Volume Cubic Feet - XA | 0.00000 |
| Visibility | Concealed |
| WC Tongue Weight | 600 |
| WD Tongue Weight | 1000 |
| Warranty | Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| Weight Carrying Capacity | 6000 |
| Weight Carrying Capacity (WC) | 6,000 LB |
| Weight Carrying Capacity(WC) | 6,000 LB |
| Weight Distribution | 10000 |
| Weight Distribution (WD) | 10,000 LB |
| Weight Distribution Tongue Weight (WDTW) | 1,000 LB |
| Weight Distribution Tongue Weight(WDTW) | 1,000 LB |
| Weight Distribution(WD) | 10,000 LB |
CURT 13028 Class 3 Hitch, 2 Receiver, Select Ford, Chevrolet, GMC C/K (Drilling Required)
Rebates for CURT 13028 Class 3 Hitch, 2 Receiver, Select Ford, Chevrolet, GMC C/K (Drilling Required)
Product Information
- Brand: CURT
- Product Number: 13028
$347.95
