CURT 15010 Commercial Duty Class 5 Trailer Hitch; 2-1/2-Inch Receiver; Compatible with Select Chevrolet Silverado; GMC Sierra 2500; 3500 HD

---

In the world of commercial towing, more is expected. A job cannot be completed if the equipment cannot handle the workload. That is why CURT developed the Commercial Duty class 5 trailer hitch. Constructed from steel and engineered for power, these class 5 hitches are designed to complement the towing power of full-size, commercial pickup trucks, including diesels and chassis cabs. They can easily handle a variety of oversize trailers, including toy and car haulers, livestock trailers, dumper trailers, large flatbed trailers, large boat trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component). This particular class 5 hitch features a gross trailer weight capacity of 20,000 lbs. and a tongue weight capacity of 2,700 lbs. It is designed to be a custom trailer hitch for certain years of the Chevrolet Silverado and GMC Sierra 2500 HD and 3500 HD (will not fit with factory receiver; to verify your vehicle compatibility, see application info). All CURT Commercial Duty class 5 hitches feature a 2-1/2 in. x 2-1/2 in. receiver tube opening to accept the strongest of ball mounts and towing accessories. They are perfect for mounting standard ball mounts, pintle mounts, tow hooks and weight distribution hitches as well as winch mounts and cargo carriers. CURT class 5 tow hitches are protected by a co-curing of liquid A-coat and carbide black powder coat finish. They also mount with grade-8 hardware, included with each hitch.

• Made w/A Vehicle-Specific Design For A Custom Fit
• Features Wide Safety Chain Openings For Heavy-Duty Hooks
• Note: Will not fit with factory receiver
• Backed By A Limited Lifetime Warranty
• Made in USA [may include imported hardware]
• Tested For Safety In Accordance w/SAE J684
• Precisely Welded For Superior Strength And Fit
• Constructed w/A Large Powerful Main Body
• Protected By A Highly Durable Carbide Powder Coat Finish
• Co-Cured In A Rust-Resistant Liquid Bonderite Coating
• Strengthened w/A Cast Welded Seamless Collar

---

Information:

Commercial Duty Class 5 Hitch, 2-1/2, Select Silverado, Sierra HD; Rated to 20,000 lbs. gross trailer weight and 2,700 lbs. tongue weight; Compatible with weight distribution hitch (20,000 lbs. WD / 2,700 lbs. WDTW); Engineered with a vehicle-specific design for a custom fit; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Constructed with a large, powerful main body; Protected by a highly durable carbide powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Features wide safety chain openings for heavy-duty hooks; Equipped with an open-back receiver for easy cleaning; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware)

---

Application Summary:

Year	Make/Model
2020-2025	Chevrolet Silverado 2500 HD
2020-2025	Chevrolet Silverado 3500 HD
2020-2025	GMC Sierra 2500 HD
2020-2025	GMC Sierra 3500 HD
