CURT 15921 44-Inch Class 5 Weld-On Hitch Center Section Only; 2-1/2-Inch Receiver; Up to 16;000 lbs
CURT weld on trailer hitch receivers offer a high-capacity, ready-to-work towing solution for your full-size truck or SUV. They are ideal for large pickup trucks, dually trucks, diesel trucks, service vehicles, flatbeds, chassis cab trucks and much more. These weldable hitches are constructed from high-strength steel and come with a standard receiver tube to accept a ball mount shank, tow hook, winch mount or other heavy-duty accessories. This CURT weld on hitch center section features a 2-1/2-inch receiver and measures 44 inches wide. It is rated for up to 20,000 pounds gross trailer weight. NOTE: This package includes the center section only. Side plates are not included.
- Adjustable Frame Fits A Variety Of Vehicles
- Fits A Max Frame Width Of 60 In. And A Minimum Of 18 In.
- Rated As A Class 5 Hitch
- Great For Use w/Utility Boxes
- Protected By A Highly Durable Carbide Powder Coat Finish
- Co-Cured In A Rust-Resistant Liquid Bonderite Coating
- Strengthened w/A Cast Welded Seamless Collar
- Made In USA
- Side Plates Do Not Come Pre-Welded
Information:
44 Universal Weld-On Hitch Center Section, 2-1/2 Receiver (No Side Plates); Frame fits a variety of vehicles (side plates not included); Measures 44 wide; Rated as a class 5 hitch; Tested for safety in accordance with SAE J684; Great for use with utility boxes; Protected by a highly durable carbide powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Made in USA
Application Summary:
Year |
Make/Model |
CURT |
15921 44-Inch Class 5 Weld-On Hitch Center Section Only, 2-1/2-Inch Receiver, Up to 20,000 lbs |
Attributes |
Box Height in Inches - XA |
13 |
Box Length in Inches - XA |
46 |
Box Width in Inches - XA |
10 |
California Proposition 65 |
Yes |
Class ID |
7 |
Container Volume Cubic Feet - XA |
0.00000 |
Container Volume Cubic Meter - XA |
0.00000 |
Country of Origin (Primary) |
US |
Emission Code |
Legal US |
Finish - XA |
GLOSS BLACK POWDER COAT |
GTIN |
00612314159215 |
Gross Trailer Weight |
20000 lbs. |
Harmonized Tariff Code (Schedule B) |
8708998180 |
Hazardous Material Code |
N |
Item Class - XA |
MFH |
Item Height - XA |
5.020 |
Item Length - XA |
44.000 |
Item Width - XA |
8.000 |
Life Cycle Status Code |
Available to Order |
Main Body Shape |
Square |
Master Case Height Inches - XA |
0.000 |
Master Case Length Inches - XA |
0.000 |
Master Case Volume Cubic Feet - XA |
0.00000 |
Master Case Weight Lbs - XA |
0.000 |
Master Case Width Inches - XA |
0.000 |
Material - XA |
Carbon Steel |
Mount Type Description - XA |
Not Applicable |
NAFTA Preference Criterion Code |
B |
Pallet Total Height Inches - XA |
0.000 |
Pallet Total Weight Per - XA |
0.000 |
Parcel Allowed - XA |
Yes |
Position |
Rear |
Price Code - XA |
14 |
Product Weight - XA |
37.000 |
Rate Class - XA |
70.0, 125.0 |
Receiver Tube Size |
2-1/2 IN |
Retail Height - XA |
0.000 |
Retail Length - XA |
0.000 |
Retail Width - XA |
0.000 |
SDR Required Flag |
N |
Sales Family Code - XA |
HITCH |
Sales Family Description - XA |
HITCH |
Sales Group Description - XA |
CL 5 |
Shipping Weight - XA |
42.000 |
Side Application Type Description - XA |
Not Applicable |
Tariff 301 - XA |
No |
Truckload Volume Cubic Feet - XA |
0.00000 |
Warranty |
Limited Lifetime |
Weight Carrying Capacity (WC) |
16,000 LB |
