CURT 15924 Class 5 Weld-On Hitch; 2-1/2-Inch Receiver; 44-In Frames; 18in. Drop

---

CURT weld on trailer hitch receivers offer a high-capacity, ready-to-work towing solution for your full-size truck or SUV. They are ideal for large pickup trucks, dually trucks, diesel trucks, service vehicles, flatbeds, chassis cab trucks and much more. These weldable hitches are constructed from high-strength steel and come with a standard receiver tube to accept a ball mount shank, tow hook, winch mount or other heavy-duty accessories. This CURT weld on receiver hitch features a 2-1/2-inch receiver with an 18-inch drop. It fits frames up to 44 inches wide. The side plates ship unattached from the center section, allowing for a flexible, adjustable installation and a custom fit. No installation hardware required! This welded universal hitch is also rated as a class 5 hitch, being fully tested to SAE J684 specifications. To protect this weld on receiver hitch from corrosion, it comes shielded with a co-cured finish of liquid A-coat and durable black powder coat.

• Adjustable Frame Fits A Variety Of Vehicles
• Fits A Max Frame Width Of 60 In. And A Minimum Of 18 In.
• Rated As A Class 5 Hitch
• Great For Use w/Utility Boxes
• Protected By A Highly Durable Carbide Powder Coat Finish
• Co-Cured In A Rust-Resistant Liquid Bonderite Coating
• Strengthened w/A Cast Welded Seamless Collar
• Made In USA
• Side Plates Do Not Come Pre-Welded

---

Information:

Adjustable frame fits a variety of vehicles (side plates do not come pre-welded); Fits truck frames up to 44 wide; Rated as a class 5 hitch; Tested for safety in accordance with SAE J684; Great for use with utility boxes; Protected by a highly durable black powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Made in USA; Universal Weld-On Trailer Hitch, 2-1/2 Receiver (Up to 44 Frames, 18 Drop)

---

Application Summary:

Year	Make/Model
CURT	15924 Class 5 Weld-On Hitch, 2-1/2-Inch Receiver, 44-In Frames, 18 Drop
