CURT 17200 Trailer Anti-Sway Bar Control Kit

---

A sway control unit is an inexpensive solution to the problem of a wandering trailer. CURT sway control units are designed to attach to your vehicle and trailer at the coupling point and counteract any lateral movement in your trailer, keeping your tow load straighter on the road and giving you more control over your vehicle. The sway bar uses a material like that used in brake pads to provide the necessary resistance while still allowing your vehicle to complete proper turns with your trailer attached. The sway control mounts onto the frame of your trailer and connects to the vehicles ball mount using a separate trailer ball from that used for coupling the trailer. CURT sway controls are adjustable and easy to install. They come with a sway unit, a trailer-mounted attachment ball and bolts, a hitch-mounted attachment ball, a weld-on tab, a mount reinforcement plate and attachment clips. Though a weight distribution hitch is not an ideal solution for trailer sway on its own, CURT weight distribution hitches are made to be combined with a sway control unit and many are available with a sway controls included for a complete package. CURT also carries ball mounts that are specially designed to work with a sway control kit, having a sway tab welded right onto the ball mount platform.

• Helps Limit Lateral Trailer Movement To Reduce Sway
• Fits Most Weight Distribution Hitches Or A Sway Tab Mount #45820
• Included Weld-On Sway Tab Allows For Use w/Most Ball Mounts
• Spacer Plate Ensures Proper Alignment Of Trailer Ball Attachment
• Features Adj. Bolt To Accommodate Different Load Sizes
• On/Off Handle Makes It Easy To Engage Or Disengage Sway Control
• Two Sway Control Units Recommended For Larger Trailers
• Compatible w/Most A-Frame Trailers (Some Drilling Required)
• Features Adjustment Bolt To Accommodate Different Load Sizes

---

Information:

Sway Control Kit; Helps limit lateral trailer movement to reduce sway; Fits most weight distribution hitches or a sway tab mount #45820; Included weld-on sway tab allows for use with most ball mounts; Spacer plate ensures proper alignment of trailer ball attachment; Features adjustment bolt to accommodate different load sizes; On / off handle makes it easy to engage or disengage sway control as needed; Two sway control units recommended for larger trailers; Compatible with most A-frame trailers (some drilling required); Limited lifetime warranty (one-year finish, one-year parts)

---
